KNIF Audio EKSA Stereo Solid State Mastering EQ
KNIF Audio EKSA Stereo Solid State Mastering EQ
IN STOCK! MINT Open-Box 4-space EksaF (with Gain and filters). Full Factory Warranty! JUST Built in October 2025 and is the latest version with new filter mods.
Or 2-3 weeks ETA if special-ordering a different version (standard or ganged)
All Customs Duties/Tariffs paid by us! No Sales Tax and Free Shipping! Pro Audio Toys is an Authorized KNIF Audio Dealer.
The already-legendary solid-state mastering EQ from Jonte at KNIF Audio.
The sound is very, very transparent. Like nothing else. Accurate but not harsh.
Eksa gets its name from the word “exact.“
Features
Five band parametric equalizer with interleaved frequency bands
MS matrix with discrete class-A operational amplifiers
Fully equipped with in-house class-A discrete op amps
Stepped Elma® switches for all rotary controls:
8-position Shelf/Q adjustment
24-position Frequency adjustment
23-position Boost/Cut with selectable range (4.5/9.0 dB)
Polypropylene capacitors in all filters
Subminiature relay switching
External power supply
Overview:
Knif Eksa is a versatile audio equalizer intended for audio mastering and mixing applications. Being an active equalizer, Eksa within the Knif product range, is the quintessential counterpart to Soma.
While inspired by legendary Sontec designs, Eksa is actually substantially more sophisticated and complex. Eksa, unlike the classic designs of the past, allows noise and wideband gain to be virtually independent of Q setting.
Eksa is equipped with MS encoding and decoding and the circuit consists of no less than 28 class-A discrete operational amplifiers crafted in-house. The circuit employs DC servos for MS, each core amplifier is meticulously calibrated to minimize their impact on the audio range. The servos boast time constants of well over one minute for absolute absence of any sonic impact.
The band gain range is adjusted in 23 steps and the range can be extended from the default ±4.5 dB to ±9 dB using the x2-mode.
All signal switching on the PCB is executed hermetically by subminiature relays with gold plated contacts (100 pieces per channel) and all capacitors in the filter circuits are polypropylene.
Eksa is available in two versions:
Eksa - the basic five band parametric equalizer.
Eksa F - identical to Eksa and comes with added gain adjustment and low-pass and high-pass filters and elliptic filtering capability.
Both Eksa and Eksa F run with an external linear power supply.
Both versions can be ordered with a channel linking option, designed to force the right channel to follow the left channel controls.
WARRANTY
2 years, Factory Warranty, plus One Year Extended Warranty from Pro Audio Toys!
